Description

• Main pipe – 100 mm / 4 inch dia, B class, Galvanised iron pipe of IS1 certified company.
•  Connecting link pipe –  48 mm / 1.5 Inch dia,  B class Galvanised iron pipe of ISO Certified company
• Handle  pip[e thickness – 32 mm dia,  B class Galvanised iron pipe of ISO certified company
• Foot rest – 4 mm thick, Mild steel, chequered plate with Proper grip E3and stopper , Grinded edges with out any sharp edges to with stand Rough usage and  Varying weather .
• Finish – Powder coated epoxy finish with thick 80 to 100 micros for Non corrosion and more life.                                                                                                                                           •All bearings used should be of 6204 quality ZZ sealed ball bearings for longer outdoor life
• Fasteners are made of stainless steel & cannot be loosened without tools
• All the open ends of pipes and bolts with socket are covered by means of LLDPE caps and base cover respectively.
  •Foundation Pipe with Anchoring Clamp should be 1.25 ‘ feet deep GI pipe supported with MS angle 25 x 25 x 6 mm . Should come with metal cup to cover the foundation ,
